- Size: 9500 * 2150 * 2150
- Place of Origin: Hebei
- Brand Name: Hebei heng auspicious molding machine
- Model Number: EPSHXEPS
- Weight: 500.000 kg
Equipment is introduced:
, the machine adopts high quality steel welded together, and after aging heat treatment, make the machine with high intensity, deformation, can withstand the expansive force of high density products.
, the machine is controlled by the PLC computer touch display screen, the machine cavity, clamping and feeding, heating, cooling, heat preservation, vacuum ejector out of the finished product, realize fully automatic cycle operation.
The cavity surface is made of special aluminum alloy plate, machine, high heat transfer efficiency, good tensile strength, long service life.
Unique through heating, machine USES the overseas advanced molding process, set up the high pressure induced air suction material, cooling, strong penetrating power, good adhesion, less steam, forming fast, low water content, guarantee products inside and outside.
- Size: 9500 * 2150 * 2150
- Place of Origin: Hebei
- Brand Name: Hebei heng auspicious molding machine
- Model Number: EPSHXEPS
- Weight: 500.000 kg
Technical parameters: the project unit PSB - Q200PSB - Q300PSB Q600PSB -- Q800
Cavity diameter mm2040 x 1020 x 5303060 x 1250 x 6306120 x 1250 x 6308160 x 1030 x 630
M31.102.414.85.3 cavity volume
Products density proportion/kg/m34.5-304.5-304.5-304.5-30
Production efficiency (standard conditions) Piece/h4-84-96-96-9
Steam pressure Mpa0.6 0.80.6-0.80.6 0.80.6-0.8
Compressed air inlet size mm6580150150
Steam inlet size mm100808080
The power V380380380380
Power kw771313
Biggest envelop dimensions mm3600 x 2000 x 2000 x 2150 x 29507500 x 2150 x 29509500 x 2150 x 2750
The weight kg30004500950010500
